N/A
88.51/7750
89.0N·m/5250 r/min
265
Intelligent Ride Modes
The T1002VX offers four adaptable riding modes for various conditions: Standard, Sport, Rainy Days, and Off-Road. These modes adjust throttle response, traction control, and braking to deliver a personalized experience for riders, whether in the city, on the highway, or off-road.
| Specification | Details |
|---|---|
| Model Name | Morbidelli T1002VX |
| Category | Trail |
| Model Year | 2024 |
| Specification | Details |
|---|---|
| Displacement (c.c) | 997 |
| Type | V-2-cylinder / 4-stroke / 8-valve / SOHC |
| Bore x Stroke | 92×75 |
| Power (hp/rpm) | 88.51/7750 |
| Max Torque | 89.0N·m/5250 r/min |
| Compression ratio | 10.3:1 |
| Ignition system | TCI |
| Starter | Electric |
| Lubrication system | Pressure splash lubrication |
| Cooling System | Liquid-cooled |
| Specification | Details |
|---|---|
| Gear shifting type | 6-speed |
| Transmission type | Chain |
| Clutch type | Slipper clutch |
| TCS | Traction Control System |
| Specification | Details |
|---|---|
| FRAME TYPE | Double-cradle |
| Front Wheel | Spokes |
| Front Suspension | Upside-down telescopic forks, restore damping adjustable, KYB |
| Front Suspension travel (mm) | 183.8 |
| Front Tyre | 120/70-19 |
| Rear Wheel | Spokes |
| Rear Suspension | Multi-link shock absorber, preload adjustable, Restore damping adjustable, KYB |
| Rear Suspension travel (mm) | 77.4 |
| Rear Tyre | 170/60-17 |
| Front Brake | Double floating discs, 4-piston caliper, J.Juan |
| Front brake diameter (mm) | 320 |
| Rear Brake | Disc, 1-piston caliper, J.Juan |
| Rear Brakes diameter (mm) | 260 |
| Specification | Details |
|---|---|
| Curb Weight (kg） | 265 |
| Seat height (mm) | 820 |
| Wheelbase | 1581 |
| Overall length (mm) | 2313 |
| Overall width (mm) | 931 |
| Overall height (mm) | 1475 |
| Ground clearance (mm) | 190 |
| Fuel Capacity (L) | 20 |
| Top speed (km/h) | 198 |
| Max Loadage (kg) | 190 |
| Battery | 12V, 14Ah |
